Estimated Acceleration Stats For Porsche 959:
0-30 MPH: 2.0 sec [1.4 sec]
0-40 MPH: 2.7 sec [1.9 sec]
0-50 MPH: 3.3 sec [2.5 sec]
0-60 MPH: 4.0 sec [3.2 sec] (100 km/h: 4,2 [3,4])
0-70 MPH: 5.0 sec [4.2 sec]
0-80 MPH: 6.0 sec [5.2 sec]
0-90 MPH: 7.1 sec [6.3 sec]
0-100 MPH: 8.7 sec [7.8 sec]
0-120 MPH: 11.9 sec [11.1 sec] (200 km/h: 12,8 [12,0])
0-150 MPH: 19.3 sec [18.5 sec] (250 km/h: 21,1 [20,3])
0-180 MPH: 33.9 sec [33.1 sec] (300 km/h: 38,4 [37,6])
0-200 MPH: 51.0 sec [50.2 sec]
Top Speed (mph): 206.5989 [207.0946]
Top Speed (km/h): 332.4887 [333.2865]
4.0+8.7/(4.0+8.7)x12.5 = 12.55sec standing quartermile time at 123mph.
Acceleration off the line: 6.737245 m/s2 = 0.69 G = 0.30sec 11.5" rollout
12.55-0.30 = 12.25 dragstrip quartermile.
With terrain-gear launch: 3.2+7.8/(3.2+7.8)x12.5 = 12.05sec standing quartermile time at 124mph.
Acceleration off the line: 9.70209 m/s2 = 0.99 G = 0.25sec 11.5" rollout
12.05-0.25 = 11.80 dragstrip quartermile.
1.0 bar (14.5 psi) of boost
cubic inches (cui)
173.88495014812392
max rpm (rpm)
6500
volumetric efficiency % (VE)
92.66
horsepower target (bhp)
443.844
Also: 345.3 cubic inches of atmospheric pressure
1620 kg curb weight including downforce, so for Komfort models it's 170 kg of downforce while for Sport models it's likely around 270 kg of downforce. In reality, they weigh around the same at higher speeds (say, post-200km/h). The car makes "official" peak power at 6500 rpm, but it really does continue to make more power toward 7500 rpm (its likely fuel cut-off, or 500 rpm above the supposed "redline"). But shifting points remain at 7000 rpm where it makes 484 mhp. The 959 makes 518-519 mhp at top speed.
Note that the test consists of both rounds: the first simulation excludes the "gelände" (terrain) gear ratio, while the other includes it.
Link to the simulator: https://x-engineer.org/projects/vehicle-acceleration-performance-online-calculator/
Engine speed @ maximum torque [rpm]
5000
Engine speed @ maximum power [rpm]
7000
Gear ratios [-] Gearbox
3.50,2.06,1.41,1.04,0.81,0.64
Differential
4.13
Wheel static radius [m]
0.318
Driveline efficiency [-]
0.85
Wheel (tire) friction coefficient [-]
1
Rear axle load coefficient [-]
1
Vehicle mass (curb) [kg]
1620
Driver mass [kg]
75
Aerodynamic drag coefficient [-]
0.31
Ambient air density [kg/m3]
1.202
Vehicle frontal area [m2]
1.793
Road slope [%]
0.00
Road load coefficient [-]
0.011
Engine speed points (full load) [rpm]
5000,5500,6500
Engine static torque points (full load) [Nm]
500,500,486
Simulation time [s]
60
